Steel-Liteâ„¢ Hollow Metal Door 36" x 84", ADA & IBC, UL Listed

Engineered for Compliance, Trusted by Inspectors.

Steel-Liteâ„¢ Hollow Metal Door 36" x 84", ADA & IBC, UL Listed - Image 1 of 0

Steel-Liteâ„¢ Hollow Metal Door 36" x 84", ADA & IBC, UL Listed - Image 2 of 0

Steel-Liteâ„¢ Hollow Metal Door 36" x 84", ADA & IBC, UL Listed - Image 3 of 0

Steel-Liteâ„¢ Hollow Metal Door 36" x 84", ADA & IBC, UL Listed - Image 4 of 0

Steel-Liteâ„¢ Hollow Metal Door 36" x 84", ADA & IBC, UL Listed - Image 5 of 0

Steel-Lite™ 36" x 84" Hollow Metal Door, RH Reverse, 18-Gauge Galvannealed Steel, NFPA 80 Fire-Rated Options, ADA & IBC Compliant, UL Listed, Prime Gray Finish, Drywall Interior Wall Frame with Panic Bar and Lever Trim, USA Made (3–4 Week Production)

List Price: $6,034.36

Savings: $

Item Return Policy: Assembled Per Order, Non-Returnable

Choose your options:

Frame Jamb Depth:

5-7/8" Jamb Depth (Wraps a 2 x 4 wall with 5/8 in. drywall on each side)

5-5/8" Jamb Depth (Wraps a 2 x 4 wall with 1/2 in. drywall on each side)

4-3/4" Jamb Depth (Wraps Around A 3-3/4" Thick Wall)

6-1/4" Jamb Depth (Wraps Around A 5-1/4" Thick Wall)

6-5/8" Jamb Depth (Wraps Around A 5-5/8" Thick Wall)

7-1/8" Jamb Depth (Wraps a 2 x 4 wall with 2 layers Of 5/8 in. drywall on each side)

7-3/4" Jamb Depth (Wraps a 2 x 6 wall with 5/8 in. drywall on each side)

8-1/4" Jamb Depth (Wraps Around A 7-1/4" Thick Wall)

8-3/4" Jamb Depth (Wraps a 7-3/4" Thick Wall)

ADA Glass Window

ADA Glass Window:

No Thanks

6 in. Wide x 27 in. Narrow Window, 1/4" Tempered Clear Glass (No Fire Label)

6 in. Wide x 27 in. Tall Fire Rated Narrow Window, 1/4" Laminated Wire Glass

12 in. Wide x 12 in. Square Window, 1/4" Tempered Clear Glass (No Fire Label)

12 in. Wide x 12 in. Tall Fire Rated Square Window, 1/4" Laminated Wire Glass

24 in. Wide x 30 in. Tall Half Lite Window, 1/4" Tempered Clear Glass (No Fire Label)

24in. x 64 in. Full Lite Window, 1/4" Tempered Clear Glass (No Fire Label)

Product Code: SLT-DW-3070-PB-RHR

Inspection-Ready, Built to Spec, 3 to 4 Week Production

Orders Over $200 Qualify for FREE SHIPPING!

Qty:

Steel-Lite™ 36" x 84" Hollow Metal Door, RH Reverse, Drywall Interior Wall Frame, Panic Bar & Outside Lever Trim

Built for code-driven interiors, this USA-made Steel-Lite™ assembly emphasizes documentation and compliance:NFPA 80 Fire-Rated Options (when specified as a labeled assembly), ADA accessibility, IBC life-safety alignment, and documented UL/cUL listings. Constructed from 18-gauge galvannealed steel with a prime gray anti-rust inhibiting finish. Typical production: 3–4 weeks.

Compliance & Listings

NFPA 80 Fire-Rated Options: Available when furnished as a complete, labeled door, frame, and listed hardware set.
ADA & IBC Alignment: Clearances, operable parts, egress width, and closer settings supported when paired with compliant hardware and field conditions.
UL/cUL Documentation: Listings referenced in submittals for door/frame/hardware as applicable.
ANSI/BHMA Grade 1 Prep: Factory reinforcements for spec-grade locks, closers, hinges, and exit devices.

Note: Final compliance is determined by the complete installed assembly and the local AHJ.

Panic Hardware & Outside Trim

Panic bar (exit device): Interior free egress; performance per ANSI/BHMA A156.3 and UL 305.
Outside lever trim: Exterior operation via lever/key as specified; interior remains free egress.
Fire-rated usage: For labeled openings, use an approved fire-rated device (no mechanical dogging).

Construction & Materials

Size & Handing: 36" x 84", RH Reverse.
Skins: 18-gauge galvannealed steel (A40/A60), prime gray anti-corrosion finish for field paint.
Core: Energy-efficient polystyrene (non-rated by default).
Edges & Reinforcements: Interlocking seams with heavy backing plates at hinge, lock, closer, and device locations.

Drywall Interior Wall Frame (KD)

Knock-Down (KD) drywall frame for interior gypsum/steel- or wood-stud partitions; ships in sections for fast assembly.
Compression anchors and base anchors sized to wall construction; strike and hinge locations coordinated to hardware function.
Clearances and reveals targeted for first-time fit and smooth inspection.

Typical Applications

Education and healthcare interiors: corridors, offices, support spaces.
Government and civic interiors requiring documented listings and submittals.
Commercial tenant build-outs and mixed-use interiors needing inspection-ready assemblies.

Key Specifications

Brand	Steel-Lite™
Door Size	36" x 84"
Handing	RH Reverse
Material	18-gauge galvannealed steel, prime gray finish
Core	Polystyrene (non-rated); mineral core available per listing
Frame	Drywall interior wall frame (KD, compression/base anchors)
Compliance	NFPA 80 options; ADA & IBC alignment; UL/cUL documentation
Panic Hardware	Exit device with outside lever trim; A156.3 / UL 305
Country of Manufacture	USA
Typical Lead Time	3–4 weeks (standard configurations)

Important Notes

Fire ratings and UL/cUL labels apply only when furnished as a complete, listed assembly and installed per the listing.
ADA/IBC compliance depends on field conditions (clearances, approaches, thresholds) and the selected hardware/closer settings.
Finish paint, glazing, and accessories are supplied per quote; verify inclusions on your proposal.
