Application-First Highlights

• Environment: Interior commercial build-outs
• Wall Type:New construction wood stud partitions — pre-drywall installation
• Use Cases: Corridors, offices, classrooms, storage & utility rooms
• Finish: Prime Gray (ready for field topcoat)

Compliance & Listing Options

• NFPA 80 fire-rated options with UL/cUL labeling available when supplied and installed as acomplete labeled assembly (door, frame, listed hardware) per UL procedure.
• ADA & IBC alignment for clear width, approach, operable parts, and closer force/speed when properly adjusted.
• Hardware readiness: Factory preps offered for ANSI/BHMA Grade 1 hinges, locks/exit devices, and closers.

Note: If a fire label is required, specify a rated core and matching listed components per the project’s UL listing and AHJ requirements.

Door Construction

• Size & Handing: 36" x 84", RHR (Right Hand Reverse)
• Skins:18-gauge galvannealed steel (A40/A60), prime painted
• Core: Insulated or fire-rated core available per specification/listing
• Edges & Reinforcements: Interlocked edges; reinforcement plates at hinges, lock/exit device, and closer
• Finish: Prime Gray (field topcoat by others)

Frame & Installation – New Construction Wood Stud (Pre-Drywall)

• Anchor frame with wood stud anchors designed to attach directly to wood studs
• Pre-drywall workflow: Set frame before gypsum board; plumb/square, anchor to studs withlarge wood screws, then board tight to frame returns
• Factory preps: Strike, silencers, hinge/closer backing aligned to hardware schedule and RHR handing
• Clearances: Coordinated reveals target first-time fit and smooth inspection

Options & Accessories

• Hardware kits (Grade 1 hinges, locksets or exit devices, closers) to match listing and ADA performance
• Vision lites / louvers (fire-rated where permitted by code and listing)
• Perimeter seals & thresholds for smoke/draft control where required

Performance Advantages

• Spec-grade build: 18-ga galvannealed skins with robust reinforcements
• Inspection-ready sequencing: Pre-drywall frame install simplifies scheduling and punch-list
• USA-made: Consistent quality with 3–4 week standard production

Key Specifications

Important Notes

• Confirm stud species/gauge/spacing, anchor type, and rough opening against approved shop drawings prior to installation.
• Final ADA/IBC performance depends on field conditions (clearances, hardware selection, closer adjustments).
• Finish paint, glazing, and hardware kits furnished per quote—verify inclusions on your proposal.
