Compliance & Certifications

• ADA compliant approach, clearances, and operability
• IBC compliant storefront entrance assembly
• Hardware:Grade 1, UL Listed, and ANSI/BHMA certified (e.g., A156.4 closers, A156.5 locks/latches, A156.6 trim)
• Glazing: 1/4" tempered safety glass for commercial storefront use

Key Features

• Medium stile construction:3-1/2" vertical stiles for standard-duty, moderate-traffic applications
• Door size (pair): 72" x 80" overall; two leaves nominally 36" x 80" each
• Glazing: 1/4" tempered safety glass, factory pre-glazed
• Finish: clear anodized, architectural-grade aluminum
• Security & operation: one active door with a commercial deadlock featuring a lock indicator, exterior key cylinder, and interior thumbturn; the inactive door uses upper and lower flush bolts that secure to the header and threshold when latched
• Weather performance: frame is fully weatherstripped; the inactive (flush-bolt) door includes high-quality pile weatherstripping at the meeting stile for an optimal seal between doors when closed

What’s Included (Pre-Installed / Packaged)

• Alumitrex™ medium stile door pair, 72" x 80" overall (two 36" x 80" leaves)
• 1/4" tempered safety glass, factory pre-glazed with commercial glazing vinyl
• Heavy-wall aluminum rails and 3-1/2" stiles (clear anodized)
• Active door:Commercial deadlock with lock indicator, exterior key cylinder, and interior thumbturn (Grade 1, UL Listed, ANSI/BHMA certified)
• Inactive door:Upper & lower flush bolts with strikes for header and threshold engagement
• Closers: Two ADA hydraulic door closers (Grade 1, UL Listed, ANSI/BHMA A156.4 compliant)
• Pivots/Hinges: Heavy-duty pivot set or hinge set (ANSI/BHMA certified)
• Trim:Exterior pull and interior push bar on the active door (ANSI/BHMA A156.6 compliant)
• Weatherstripping:Full frame weatherstrip plus high-density pile weatherstrip on inactive door meeting stile
• Threshold: Commercial aluminum threshold, prepped to accept lower flush bolt
• Fastener kit for storefront hardware components

All primary hardware components are Grade 1, UL Listed, and ANSI/BHMA certified for reliable performance.

Wall Type & Mounting (Exterior Steel Stud Wall with Veneer)

Designed for exterior steel stud framing with veneer facades (brick, stone, stucco, or architectural panels). Provide continuous backing at jambs and head (e.g., doubled or tube steel king/jack studs and an engineered header). Coordinate WRB, flashing, and sealants with the facade and threshold details.

• Anchor frame to steel studs/header using appropriate self-drilling screws into structural members or clip/plate connections per engineer-of-record (by installer)
• Shim at manufacturer-recommended points to maintain plumb, level, and square
• Integrate pan/threshold seal, end dams, and WRB flashing with the veneer system
• Seal perimeter with commercial-grade backer rod and sealant compatible with facade materials
• Verify smooth swing on both leaves, deadlock engagement on the active door, and flush bolt engagement at header/threshold on the inactive door

Anchoring fasteners for steel studs are not included, allowing the installer to select diameter and length suitable for stud gauge, sheathing thickness, and header design.

Specifications

• Nominal Size (Pair): 72" x 80"
• Configuration: Active / Inactive pair (inactive leaf with upper & lower flush bolts)
• Stile Width:3-1/2" vertical stiles (medium stile)
• Glazing: 1/4" tempered safety glass, pre-glazed
• Material/Finish: heavy-wall aluminum, clear anodized
• Hardware: Grade 1 UL Listed, ANSI/BHMA certified (closers, deadlock, pivots/hinges, trim, flush bolts)
• Weatherstripping: full-perimeter frame weatherstrip + pile meet-stile weatherstrip on inactive leaf
• Use: standard-duty, moderate-traffic commercial entrances
• Origin: Made in USA
• Production: 3-4 week lead time

Quality & Packaging

• Factory pre-glazing and hardware prep to reduce install time
• Protective wrapping and heavy-duty crating for freight transit
• Installation instructions included

Notes

• Verify rough opening, stud layout, sheathing thickness, and engineered header prior to ordering
• Coordinate waterproofing, pan flashing, thermal breaks as needed, and perimeter sealant with site conditions
• Site-specific conditions may require alternate anchors or sealants (by installer)
