Steel-Lite 48" x 96" Pre-Hung Hollow Metal Door â€“ Welded Punch & Dimple Frame, Existing Metal Stud Retrofit, Grade 1 Hardware, USA Made (3â€“4 Week Production)

Engineered for Compliance, Trusted by Inspectors.

Steel-Lite™ 48" x 96" Pre-Hung Hollow Metal Door – RH Reverse, 18-Gauge Polystyrene Core, Welded Punch & Dimple Frame with Existing Opening Anchors for Metal Stud Walls, Grade 1 Hardware, UL Listed, Interior/Exterior, USA Made (3–4 Week Production)

$

Item Return Policy: Assembled Per Order, Non-Returnable

Choose your options:

Frame Jamb Depth:

4-3/4" Jamb Depth (3-3/4" Throat)

5-3/4" Jamb Depth (4-3/4" Throat)

6-1/4" Jamb Depth (5-1/4" Throat)

6-3/4" Jamb Depth (5-3/4" Throat)

7-1/4" Jamb Depth (6-1/4" Throat)

7-3/4" Jamb Depth (6-3/4" Throat)

8-1/4" Jamb Depth (7-1/4" Throat)

8-3/4" Jamb Depth (7-3/4" Throat)

9-1/4" Jamb Depth (8-1/4" Throat)

ADA Glass Window

ADA Glass Window:

No Thanks

6 in. Wide x 27 in. Narrow Window, 1/4" Tempered Clear Glass (No Fire Label)

6 in. Wide x 27 in. Tall Fire Rated Narrow Window, 1/4" Laminated Wire Glass

12 in. Wide x 12 in. Square Window, 1/4" Tempered Clear Glass (No Fire Label)

12 in. Wide x 12 in. Tall Fire Rated Square Window, 1/4" Laminated Wire Glass

24 in. Wide x 30 in. Tall Half Lite Window, 1/4" Tempered Clear Glass (No Fire Label)

24in. x 64 in. Full Lite Window, 1/4" Tempered Clear Glass (No Fire Label)

Frame Header:

2 in. Frame Header (Standard)

4 in. Frame Header

Product Code: PH4080-MPD-161-RHR

Inspection-Ready, Built to Spec, 3 to 4 Week Production

Orders Over $200 Qualify for FREE SHIPPING!

Qty:

Steel-Lite™ 48" x 96" Pre-Hung Hollow Metal Door - Existing Metal Stud Retrofit

Built for retrofit into existing metal stud walls, this complete pre-hung door system ships factory-assembled with a welded punch & dimple frame and Grade 1 hardware pre-installed. Designed for both interior and exterior applications, the system installs quickly with supplied self-drilling screws. Proudly USA-made with dependable 3–4 week production.

What’s Included (Pre-Installed)

Grade 1 UL Listed ANSI/BHMA Compliant Heavy Duty Door Closer
UL Listed / ADA / ANSI / BHMA Compliant Saddle Threshold
UL Listed Frame Gasket Weather Seal
UL Listed Bottom Door Sweep
Non Removable Pin Ball Bearing Hinges
Grade 1 UL Listed Entrance Lock Handle

All hardware arrives factory mounted and tuned for smooth operation.

Door & Frame Construction

Door Size & Handing: 48" x 96", RH Reverse
Skins: 18-gauge galvannealed steel (A40/A60), prime painted for field finish
Core: Polystyrene insulated core for energy-conscious performance
Edges & Reinforcements: Interlocking seams with hardware backing; hinge side reinforced for high-cycle use
Frame:Welded, punch & dimple retrofit frame engineered for existing metal stud walls
Weatherability: Complete sealing package with gasket and sweep (field sealing recommended for exterior use)

Anchoring & Installation

Set the pre-hung assembly into the existing opening; plumb, level, and shim on hinge and strike sides
Anchors align with stud locations; secure using supplied self-drilling screws into steel studs
Verify reveals and clearances; apply sealant for weather exposure when used as an exterior opening
Tip-in install: hardware and frame are factory prepped — no field hanging or drilling required

Typical Applications

Interior commercial partitions where retrofitting is required
Exterior entries in metal stud construction with minimal downtime
Retail, office, healthcare, and tenant improvement projects

Why Contractors Choose This System

Complete pre-hung package: Door, welded/dimpled frame, closer, lock, hinges, threshold, gasket, sweep
Grade 1 hardware: UL Listed, ANSI/BHMA compliant for heavy-duty service
Fast retrofit: Supplied self-drilling screws simplify attachment to metal studs
USA-made: Consistent quality and 3–4 week production

Key Specifications

Brand	Steel-Lite™
Size	48" x 96"
Handing	RH Reverse
Door Skins	18-gauge galvannealed steel, prime painted
Core	Polystyrene insulated
Frame	Welded, punch & dimple retrofit frame for existing metal stud walls
Hardware	Factory pre-installed Grade 1 UL Listed closer, lock, hinges, threshold, gasket, and sweep
Listings	UL Listed components; complete factory-assembled system
Use	Interior or Exterior (sealant recommended for exterior)
Country of Manufacture	USA
Typical Lead Time	3–4 weeks

Important Notes

ADA performance (clearances, approach, closer force/speed) depends on field conditions and installation.
Finish painting, glazing, and specialty accessories are furnished per quote; confirm inclusions on your proposal.
