Pair Configuration

• Active/Inactive: RH Reverse active leaf (locks & latches); inactive leaf prepped for surface or concealed flush bolts.
• Meeting stile: Astragal and coordinator options available for correct closing sequence and security.
• Egress & swing: Configurable to project requirements while supporting clear width and approach criteria.
• Hardware preps: Reinforcements for ANSI/BHMA Grade 1 hinges, mortise/cylindrical lock, closer, strike; exit device preps available.

Door Construction

• Skins: 18-ga galvannealed steel for corrosion resistance and superior paint adhesion.
• Finish: Factory prime gray, ready for field topcoat.
• Core: Polystyrene insulated (standard) for rigidity and thermal performance.
• Edges & seams: Interlocked, mechanically seamed edges with heavy backing plates at hardware locations.
• Glazing/vents: Vision lite and louver options available (per code/spec).

New Metal Stud Wall Anchor Frame (KD)

• Application: Designed for new construction metal stud partitions.
• Anchorage: Anchor frame with stud/strap anchors for positive attachment to steel studs; base anchors included.
• KD assembly: Ships knock-down for easier handling and faster, square installation in the rough opening.
• Sealability: Prepped to accept thresholds, sweeps, and perimeter weatherstripping when required.

Compliance & Ratings

• NFPA 80 Fire-Rated Options: 20/45/60/90-minute labels available when supplied as a complete labeled assembly.
• ADA & IBC: Clear opening, approach, closer forces, and operable parts supported when paired with appropriate hardware and field conditions.
• UL/cUL: Door, frame, and hardware preps compatible with UL-listed components for inspection-ready submittals.

Key Specifications
