Phoenix Architectural Hardware Titan 44 Series Rim Exit Device - Model 44E0-3 - Fits 28" to 36" Medium Stile Hollow Metal or Wood Doors - Aluminum Finish - Allen Key Dogging, 2-3/4" Backset, 5/8" Stainless Steel Latch - Grade 1, UL Listed

Phoenix Architectural Hardware Titan 44 Series Rim Exit Device – Model 44E0-3 is a heavy-duty, ANSI Grade 1 panic bar engineered for medium stile commercial doors. Designed with a universal, non-handed chassis, this exit device provides reliable performance on both hollow metal and wood doors, making it ideal for retail storefronts, offices, schools, and other high-traffic facilities.

The Titan 44 Series rim exit device features a 4-1/2" minimum stile requirement for proper installation and includes a stainless steel 5/8" throw latch with deadlatch feature for enhanced security and durability. The device has a 2-3/4" backset and the rail can be cut down to fit door widths ranging from 28" to 36". The Allen key dogging allows the bar to be held in the unlatched position for push/pull operation during business hours, improving convenience and energy efficiency.

• Model: 44E0-3 (Rim Exit Device for Single 36" Door)
• Door Type: Hollow metal or wood
• Minimum Stile: 4-1/2" for rim applications
• Latch: 5/8" stainless steel throw latch with deadlatch
• Backset: 2-3/4"
• Rail Size: Cuttable to fit 28"–36" door widths
• Design: Non-handed, field reversible
• Finish: Aluminum (AL)
• Dogging: Allen key dogging standard
• Compliance: ANSI/BHMA A156.3 Grade 1
• Listings: UL Listed for panic hardware

Built for long-term strength and smooth operation, the Titan 44 Series provides a cost-effective, code-compliant egress solution for single-door commercial applications. Its medium-stile compatibility and adjustable rail design make it versatile for a wide range of installations.
