What’s Included (Turnkey)

• Door Slab: 36" x 84", LHR (Left Hand Reverse), 18-gauge galvannealed steel skins, prime painted for field finish.
• Fire-Rated Core: Engineered fire-rated core qualified for 90 minute labeling.
• Frame:Punch & dimple KD masonry frame for existing CMU/block walls; ships knock-down for easier handling.
• Anchoring: Sleeve/expansion anchors for block; shims and fasteners included. (Grout if required by listing/AHJ or project spec.)
• UL Listed Grade 1 Hardware Package: fire-rated ball-bearing hinges, fire-rated closer, and Grade 1 fire-rated lockset (standard). Exit device available by request.
• Documentation: UL/cUL labels and submittals to support inspection.

Compliance & Certifications

• 90 Minute B Label (1-1/2 Hour) door & frame assembly tested to NFPA 80.
• UL/cUL Listed complete system (door, KD frame, and listed hardware set).
• ADA & IBC alignment: clear width, approach, operable parts, and closer force/speed when adjusted properly.
• ANSI/BHMA Grade 1 hardware for durability and smooth inspection.

Important: Rating and labels apply only when supplied and installed as a complete labeled assembly per UL procedure and local AHJ requirements.

Door Construction

• Size & Handing: 36" x 84", LHR (Left Hand Reverse).
• Skins: 18-gauge galvannealed steel (A40/A60), prime painted.
• Core: Fire-rated core for B Label assemblies.
• Edges & Reinforcements: Interlocked edges; reinforcement plates at hinges, lock, and closer.

Frame & Anchoring – Existing Block Wall Opening

• KD punch & dimple masonry frame for CMU/block substrates, supplied knock-down.
• Anchors: Sleeve/expansion anchors set into block; fasten per shop drawings and listing.
• Factory strike and silencer locations matched to LHR handing and included hardware.
• Clearances/reveals coordinated for first-time fit and clean inspection.

Included Fire-Rated Hardware

• Hinges: UL listed fire-rated ball-bearing hinges (quantity/type per door size and listing).
• Lockset:Grade 1 UL fire-rated lockset (function/trim per specification).
• Closer: Fire-rated closer with adjustable sweep and latch; ADA force compliance when adjusted properly.
• Perimeter/Smoke Seals & Threshold (if specified): Components matched to listing and opening condition.

Performance Advantages

• Inspection-Ready: Coordinated, labeled system minimizes RFIs and rework.
• Serviceability: KD frame simplifies transport, handling, and field assembly.
• Spec-Grade Durability: 18-gauge steel + Grade 1 hardware for long service life.
• USA Made: Consistent quality with 3–4 week production for standard builds.

Typical Applications

• Stair enclosures, corridors, and fire barriers in CMU/block construction.
• Retrofit conditions where existing block wall openings require a 90 minute UL listed assembly.
• Commercial, healthcare, education, civic, and industrial facilities with documented code requirements.
