36" x 84" RHR Hollow Metal Door - KD Punch & Dimple for Exterior Steel Stud | Steel-Liteâ„¢

Engineered for Compliance, Trusted by Inspectors.

36" x 84" RHR Hollow Metal Door - KD Punch & Dimple for Exterior Steel Stud | Steel-Liteâ„¢ - Image 1 of 0

36" x 84" RHR Hollow Metal Door - KD Punch & Dimple for Exterior Steel Stud | Steel-Liteâ„¢ - Video 2 of 1

Steel-Lite™ 36" x 84" Hollow Metal Door, RHR, 18-ga Galvannealed, NFPA 80 Options, ADA/IBC, UL Listed, Prime Gray, KD Punch & Dimple Frame w/ Screws for Exterior Steel Stud Wall (Brick/Stone/Stucco Veneer), USA Made (3–4 Week Production)

List Price: $4,886.36

Savings: $

Choose your options:

Frame Jamb Depth:

4-3/4" Jamb Depth (3-3/4" Throat)

5-3/4" Jamb Depth (4-3/4" Throat)

6-1/4" Jamb Depth (5-1/4" Throat)

6-3/4" Jamb Depth (5-3/4" Throat)

7-1/4" Jamb Depth (6-1/4" Throat)

7-3/4" Jamb Depth (6-3/4" Throat)

8-1/4" Jamb Depth (7-1/4" Throat)

8-3/4" Jamb Depth (7-3/4" Throat)

9-1/4" Jamb Depth (8-1/4" Throat)

ADA Glass Window

ADA Glass Window:

No Thanks

6 in. Wide x 27 in. Narrow Window, 1/4" Tempered Clear Glass (No Fire Label)

6 in. Wide x 27 in. Tall Fire Rated Narrow Window, 1/4" Laminated Wire Glass

12 in. Wide x 12 in. Square Window, 1/4" Tempered Clear Glass (No Fire Label)

12 in. Wide x 12 in. Tall Fire Rated Square Window, 1/4" Laminated Wire Glass

24 in. Wide x 30 in. Tall Half Lite Window, 1/4" Tempered Clear Glass (No Fire Label)

24in. x 64 in. Full Lite Window, 1/4" Tempered Clear Glass (No Fire Label)

Product Code: SLTEOAM3070RHR

Inspection-Ready, Built to Spec, 3 to 4 Week Production

Orders Over $200 Qualify for FREE SHIPPING!

Qty:

Steel-Lite™ 36" x 84" Hollow Metal Door - RHR (Exterior Steel Stud Wall: Brick/Stone/Stucco Veneer)

Purpose-built for exterior steel stud wall assemblies behind brick, stone, or stucco veneer, this Steel-Lite™ package pairs a36" x 84" Right Hand Reverse (RHR) hollow metal door with a KD punch & dimple frame engineered for direct attachment to steel studs using theincluded screws. Supplied in Prime Gray, with NFPA 80 fire-rated options and UL/cUL listing available when furnished as a complete labeled assembly.USA Made, typical 3–4 week production.

Application-Focused Overview

Wall Type: Steel stud framing with exterior veneer claddings (brick, stone, stucco/EIFS, fiber-cement, metal panel)
Use: Exterior entrances, service doors, and egress points in commercial & institutional projects
Envelope Coordination: Works with sheathing, air/water barriers, flashing, threshold, and perimeter weather seals
Handing:RHR (Right Hand Reverse)

Compliance & Listing Options

NFPA 80 fire-rated options with UL/cUL labels when supplied and installed as acomplete labeled assembly (door, frame, listed hardware) per UL procedure.
ADA & IBC alignment: clear width, approach, operable parts, and closer force/speed when properly adjusted.
Hardware readiness: Factory preps available for ANSI/BHMA Grade 1 closers, hinges, and locks/exit devices.

Note: Standard insulated cores are non-rated. If a fire label is required, specify afire-rated core and listed components to match the UL listing and AHJ requirements.

Door Construction

Skins:18-gauge galvannealed steel (A40/A60) for superior paint adhesion; supplied Prime Gray for field topcoat
Core: Insulated by default; fire-rated core available per specification/listing
Edges & Reinforcements: Interlocked edges with reinforcement plates at hinges, lock/exit device, and closer
Exterior Readiness: Pair with threshold, drip edge, and perimeter weather seals per project conditions

Frame & Attachment – Exterior Steel Stud Wall

KD (knock-down) punch & dimple frame designed for stiffness, consistent reveals, and clean inspection
Screws included for attachment to steel studs (use shop drawings for spacing and edge distances)
Façade Integration: Coordinate with veneer, sheathing, and air/water barrier continuity; use backer rod & sealant and flashing at perimeters
Factory strike and silencers located for RHR handing; clearances set for first-time fit

Performance Advantages

Envelope-friendly: Details support proper interface with veneer and weather barrier systems
Spec-grade durability: 18-ga steel skins with robust hardware reinforcements
Inspection-ready: Code-aligned design and labeling options minimize RFIs
USA Made: Consistent quality with 3–4 week standard production
