Compliance & Certifications

• ADA compliant approach, clearances, and operability
• IBC compliant storefront entrance assembly
• Hardware:Grade 1, UL Listed, and ANSI/BHMA certified (e.g., A156.4 closers, A156.5 locks/latches, A156.6 architectural trim)
• Glazing: 1/4" tempered safety glass suitable for commercial storefront use

Key Features

• Narrow stile construction:2" vertical stiles for slim, modern sightlines (light-duty, low-traffic)
• Door size: 36" x 84" (RH handing)
• Glazing: 1/4" tempered safety glass, factory pre-glazed
• Finish: clear anodized, architectural-grade aluminum
• Purpose-built for pre-cast concrete wall openings

What’s Included (Pre-Installed / Packaged)

• Alumitrex™ narrow stile storefront door leaf, 36" x 84", RH
• 1/4" tempered safety glass, factory pre-glazed with commercial glazing vinyl
• Heavy-wall aluminum rails and 2" stiles (clear anodized)
• Deadbolt lock (Grade 1, UL Listed, ANSI/BHMA certified)
• ADA hydraulic door closer (Grade 1, UL Listed, ANSI/BHMA A156.4 compliant)
• Pivot hinges (top and bottom; ANSI/BHMA certified)
• Exterior: Solid aluminum pull | Interior:push bar (ANSI/BHMA A156.6 compliant)
• Fastener kit for storefront hardware components

All primary hardware components are Grade 1, UL Listed, and ANSI/BHMA certified for dependable operation.

Wall Type & Mounting (Exterior Pre-Cast Concrete)

Designed for pre-cast concrete panels (solid or sandwich) with appropriate structural backing. Typical installation uses concrete-rated anchors or embedded inserts at jambs and threshold, coordinated with the project’s structural details. Ensure the substrate is plumb, level, and structurally sound prior to installation.

• Anchor at manufacturer-recommended points; verify edge distances and embedment
• Shim to maintain plumb, level, and square during fastening
• Coordinate WRB transitions, flashing, and sealant continuity at the perimeter
• Verify smooth swing, latch engagement, and ADA approach clearances

Concrete anchors or embedded inserts are not included, allowing the installer to select type, diameter, and embedment to meet panel design and engineer requirements.

Specifications

• Nominal Size: 36" x 84"
• Handing: RH
• Stile Width:2" vertical stiles (narrow stile)
• Glazing: 1/4" tempered safety glass, pre-glazed
• Material/Finish: heavy-wall aluminum, clear anodized
• Hardware: Grade 1 UL Listed, ANSI/BHMA certified (closer, lock, pivots, pull/push)
• Use: light-duty, low-traffic commercial entrances
• Origin: Made in USA
• Production: 3–4 week lead time

Quality & Packaging

• Factory pre-glazing and hardware prep to reduce install time
• Protective wrapping and heavy-duty crating for freight transit
• Installation instructions included

Notes

• Verify rough opening dimensions, panel thickness, and backup structure prior to ordering
• Coordinate threshold transition and waterproofing with site conditions
• Site-specific conditions may require alternate anchors or sealants (by installer)
