Application Fit

• Opening Size: Designed for existing 38" wide x 85" tall drywall openings.
• Wall Build: For 2x3 steel stud walls with 5/8" drywall each side (≈ 3-3/4" overall thickness).
• Handing: Right Hand Reverse (RHR).
• Use Case: Ideal for commercial interiors where lighter partitions need a durable steel door upgrade.

Door Construction

• Skins: 18-gauge galvannealed steel with prime gray, paint-ready finish.
• Core: Polystyrene insulated for strength, thermal efficiency, and rigidity (non-rated).
• Edges & Reinforcements: Interlocked seams with heavy-duty reinforcements at hinge and lock areas.
• Prep: Factory prepped for standard commercial hardware including hinges and locksets.

KD Slip-On Frame for 3-3/4" Walls

• Type: Knock-down slip-on frame designed to retrofit drywall openings.
• Fit: Sized for 3-3/4" overall wall thickness (2x3 studs + 5/8" drywall each side).
• Anchorage: Secures with compression anchors and base fasteners into existing studs.
• Installation: Ships in sections for easy handling and quick assembly on site.

Advantages

• Retrofit-ready design for fast installation with no wall tear-out.
• Accurate fit for 2x3 steel stud drywall walls with 5/8" board each side.
• Prime coat finish ready for field paint to match interiors.
• USA made with consistent 3–4 week production times.

Key Specifications
