Compliance & Certifications

• ADA compliant for approach, operation, and clearance requirements
• IBC compliant storefront entrance assembly
• Hardware:Grade 1, UL Listed, and ANSI/BHMA certified (A156.4 closers, A156.5 locks/latches, A156.6 trim)
• Glazing: 1/4" tempered safety glass approved for commercial use

Key Features

• Narrow stile construction:2" vertical stiles for minimal sightlines in light-duty, low-traffic environments
• Door size: 48" x 80" (LH handing)
• Glazing: 1/4" tempered safety glass, factory pre-glazed
• Finish: clear anodized, architectural-grade aluminum
• Purpose-built for exterior steel stud wall with veneer openings

What’s Included (Pre-Installed / Packaged)

• Alumitrex™ narrow stile storefront door leaf, 48" x 80", LH
• 1/4" tempered safety glass, pre-glazed with commercial glazing vinyl
• Heavy-wall aluminum rails and 2" stiles (clear anodized)
• Deadbolt lock (Grade 1, UL Listed, ANSI/BHMA certified)
• ADA hydraulic door closer (Grade 1, UL Listed, ANSI/BHMA A156.4 compliant)
• Pivot hinges (top and bottom; ANSI/BHMA certified)
• Exterior: Solid aluminum pull | Interior:push bar (ANSI/BHMA A156.6 compliant)
• Fastener kit for storefront hardware components

All hardware components are Grade 1, UL Listed, and ANSI/BHMA certified to ensure lasting performance.

Wall Type & Mounting (Exterior Steel Stud Wall with Veneer)

Designed for exterior steel stud framing with a veneer façade (brick, stone, stucco, or architectural panel). Provide continuous backing at jambs and header. Coordinate waterproofing, sealants, and flashing with façade cladding and threshold conditions for long-term performance.

• Anchor into structural studs or header using self-drilling or engineered fasteners (by installer)
• Shim as needed to maintain plumb, level, and square alignment
• Seal perimeter with commercial-grade sealant and backer rod
• Confirm latch alignment, swing clearance, and ADA compliance

Anchoring fasteners for steel stud walls are not included, allowing the installer to select the appropriate type and length for framing and sheathing conditions.

Specifications

• Nominal Size: 48" x 80"
• Handing: LH
• Stile Width:2" vertical stiles (narrow stile)
• Glazing: 1/4" tempered safety glass, pre-glazed
• Material/Finish: heavy-wall aluminum, clear anodized
• Hardware: Grade 1 UL Listed, ANSI/BHMA certified (closer, lock, pivots, pull/push)
• Use: light-duty, low-traffic commercial entrances
• Origin: Made in USA
• Production: 3–4 week lead time

Quality & Packaging

• Factory pre-glazing and hardware prep for simplified installation
• Protective wrapping and heavy-duty crating for secure transit
• Installation instructions included

Notes

• Verify rough opening, framing layout, sheathing thickness, and veneer details before ordering
• Coordinate waterproofing and threshold integration with site-specific conditions
• Alternate anchors or sealants may be required for unique wall assemblies (by installer)
