Compliance & Certifications

• ADA compliant approach, clearances, and operability
• IBC compliant storefront entrance assembly
• Hardware:Grade 1, UL Listed, and ANSI/BHMA certified (e.g., A156.4 closers, A156.5 locks/latches, A156.6 architectural trim)
• Glazing: 1/4" tempered safety glass for commercial storefront use

Key Features

• Medium stile construction:3-1/2" vertical stiles for standard-duty, moderate-traffic applications
• Door size: 48" x 84" (LH handing)
• Glazing: 1/4" tempered safety glass, factory pre-glazed
• Finish: clear anodized, architectural-grade aluminum
• Purpose-built for block / CMU wall openings

What’s Included (Pre-Installed / Packaged)

• Alumitrex™ medium stile storefront door leaf, 48" x 84", LH
• 1/4" tempered safety glass, factory pre-glazed with commercial glazing vinyl
• Heavy-wall aluminum rails and 3-1/2" stiles (clear anodized)
• Heavy-duty deadbolt (Grade 1, UL Listed, ANSI/BHMA certified)
• ADA hydraulic door closer (Grade 1, UL Listed, ANSI/BHMA A156.4 compliant)
• Heavy-duty pivot hinges (top and bottom; ANSI/BHMA certified)
• Exterior: Solid aluminum pull | Interior:push bar (ANSI/BHMA A156.6 compliant)
• Fastener kit for storefront hardware components

All primary hardware components are Grade 1, UL Listed, and ANSI/BHMA certified for reliable performance.

Wall Type & Mounting (Exterior Block / CMU Wall)

Designed for CMU/masonry block substrates. Typical installation uses masonry-rated anchors at jambs and threshold (furnished by installer to match block density and site conditions). Ensure the substrate is plumb, level, and structurally sound before installation.

• Anchor with appropriate masonry fasteners at manufacturer-recommended locations
• Shim to maintain plumb, level, and square during fastening
• Seal perimeter with commercial-grade backer rod and sealant; coordinate sill/threshold flashing
• Verify smooth swing, latch engagement, and ADA approach clearances

Dynabolts for CMU/block anchoring are not included, allowing the installer to select diameter and embedment suitable for the project’s specific wall conditions.

Specifications

• Nominal Size: 48" x 84"
• Handing: LH
• Stile Width:3-1/2" vertical stiles (medium stile)
• Glazing: 1/4" tempered safety glass, pre-glazed
• Material/Finish: heavy-wall aluminum, clear anodized
• Hardware: Grade 1 UL Listed, ANSI/BHMA certified (closer, lock, pivots, pull/push)
• Use: standard-duty, moderate-traffic commercial entrances
• Origin: Made in USA
• Production: 3–4 week lead time

Quality & Packaging

• Factory pre-glazing and hardware prep to reduce install time
• Protective wrapping and heavy-duty crating for freight transit
• Installation instructions included

Notes

• Verify rough opening and block condition prior to ordering
• Coordinate threshold transition and waterproofing details with site conditions
• Site-specific conditions may require alternate anchors or sealants (by installer)
