GapFix™ ADA & Fire-Rated Commercial Door Threshold - 5" x 1/2" x 168", Mill Finish Aluminum, UL Listed, ANSI/BHMA Certified, Made in USA (7 Day Production Time)

Barrier-Free 1/2" Saddle Threshold for Commercial & Fire-Rated Openings

The GapFix™ 5" x 1/2" x 168" Commercial Door Threshold in Mill Finish Aluminum is engineered for commercial openings requiring ADA accessibility, fire door compliance, and long-term durability.

With a 5" profile width, 1/2" ADA-compliant height, heavy-duty .109" wall thickness, and a 1000 lb load rating, this threshold is built for high-traffic commercial environments.

Made in USA and manufactured per order (7 Day Production Time).

Hole Configuration Options

Choose the configuration that best fits your installation requirements:

• Pre-Punched Holes: Evenly spaced factory-punched mounting holes for fast, consistent installation.
• No Pre-Punched Holes: Clean profile for field drilling, custom anchor placement, or architectural preference.

Pre-punched thresholds are ideal for standard installations. Non-punched thresholds are often specified when precise anchor spacing or concealed fastening layouts are required.

Certifications & Compliance

• ADA Compliant: Meets ADA Standards for Accessible Design
• ICC/ANSI A117.1: Accessible and Usable Buildings and Facilities
• UL Positive Pressure Certified: ANSI/UL10C
• Fire Door Certified: CAN/ULC-S104 and ANSI/UL10B
• Complies with NFPA 80 & NFPA 252
• ANSI/BHMA A156.21 Certified
• Listed in the BHMA Certified Products Directory

Approved for use with Hollow Metal fire doors rated up to 3 hours and Wood fire doors rated up to 90 minutes.

Product Specifications

• Brand: GapFix™
• Material: 6063 Aluminum
• Finish: Mill Finish Aluminum
• Length: 168"
• Profile Width: 5"
• Height: 1/2"
• Wall Thickness: .109"
• Load Rating: Up to 1000 lbs
• Country of Origin: Made in USA

Includes

• 1 Each 168" GapFix™ 5" x 1/2" Saddle Threshold
• #10 x 1-1/2" Flat Head (FH) Zinc Plated Wood Screws (when pre-punched option is selected)

For concrete slab installations, appropriate masonry anchors should be used.

Installation Resources

📘 View Step-by-Step Commercial Threshold Installation Article

📄 Download Threshold Installation PDF

Watch Installation Videos

Why Choose GapFix™?

• Commercial-grade Mill Finish Aluminum construction
• ADA compliant 1/2" barrier-free profile
• UL certified for fire-rated applications
• ANSI/BHMA A156.21 certified
• Heavy-duty .109" wall and 1000 lb load rating
• Made in USA - manufactured per order
• Available with or without pre-punched mounting holes

GapFix™ — Fix the Opening, Not Just the Hardware.
