Entry Systems ES4 Rim Exit Device with Outside Rim Cylinder - Fits 28" to 36" Medium Stile Hollow Metal or Wood Doors - Aluminum Finish - Schlage C Keyway, Dogging, 2-3/4" Backset, 5/8" Stainless Steel Latch - Grade 1, UL Listed

The Entry Systems ES4 with Outside Rim Cylinder is a Grade 1 rim exit device designed for medium stile commercial doors between 28" and 36" wide. This version includes an exterior Schlage C keyway rim cylinder that provides key-controlled entry while allowing free egress from inside.

The device features a stainless steel 5/8" throw latch with deadlatch, a 2-3/4" backset, and a 4-1/2" minimum stile. The rail can be cut down to size. As a non-fire-rated model, it includes Allen key dogging for hold-open operation.

• Model: ES4 (Rim Exit Device with Rim Cylinder)
• Door Width: 28"–36"
• Cylinder: Schlage C keyway rim cylinder (keys included)
• Dogging: Yes (Allen key)
• Latch: 5/8" stainless steel throw latch with deadlatch
• Backset: 2-3/4"
• Design: Non-handed, field reversible
• Finish: Aluminum (AL)
• Compliance: ANSI/BHMA A156.3 Grade 1
• Listings: UL Listed for panic hardware
