ES4100 Grade 1 Regular Arm Door Closer - Aluminum Finish - Adjustable Spring Power - Separate Sweep, Latch & Backcheck Valves - UL 10C Fire Rated
$
Item Return Policy: Assembled Per Order, Non-Returnable
Product Code: ES4100-RA-ALUM
Usually Ships in 24 Hours
Orders Over $200 Qualify for FREE SHIPPING!
Entry Systems ES4100 Grade 1 Regular Arm Door Closer - Aluminum Finish - Adjustable Spring Power - Separate Sweep, Latch & Backcheck Valves - UL 10C Fire Rated
The Entry Systems ES4100 Series Regular Arm Door Closer in Aluminum finish is engineered for medium to heavy duty commercial applications requiring a standard pull-side mount. This configuration delivers the strongest closing force and most efficient mechanical leverage of any surface-mounted door closer, making it ideal for high-traffic commercial doors and exterior openings.
Equipped with adjustable spring power and separate sweep, latch, and backcheck valves, the ES4100-RA-ALUM provides full control of the door closing cycle while meeting ADA and ANSI A117.1 barrier-free operation requirements.
Key Features
ANSI A156.4 Grade 1: Heavy duty commercial performance tested to over 2 million cycles
Regular arm mount: Strongest closing power for pull-side installations
Aluminum finish: Architectural, corrosion-resistant finish for interior or exterior doors
Adjustable spring power: One closer covers multiple door sizes and traffic conditions
Independent sweep, latch, and backcheck adjustments for precise control
Robust forged arm assembly for long-term durability in high-use environments
Full architectural cover for a clean, professional appearance
Standard template: 3/4" x 9-1/16" center-to-center mounting hole pattern
UL Listed 10C: Suitable for labeled fire door assemblies
Applications
Ideal for schools, office buildings, warehouses, retail stores, and institutional facilitiesrequiring a reliable Grade 1 closer in a standard pull-side regular arm configuration. Perfect for exterior commercial doors, corridor doors, and high-use interior openings where maximum mechanical advantage and strong latching power are required.
Compliance & Certifications
ANSI/BHMA: A156.4 Grade 1
Accessibility: ADA & ANSI A117.1 compliant
Fire Rating: UL Listed 10C
Included Components
Entry Systems ES4100 Series closer body with full architectural cover (Aluminum finish)
Regular arm assembly (standard mount)
Mounting hardware and installation instructions
Technical Specifications
Spring Power: Adjustable multi-size
Valves: Independent sweep, latch, and backcheck
Mounting Hole Pattern: 3/4" x 9-1/16" CTC
Fluid: All-weather hydraulic
Bearings: Needle bearing construction
Cover: Full architectural cover
Finish: Aluminum (ALUM)
Architectural Submittals
The following documents are provided for architectural specification, project submittals, and contractor use. These files include all technical details required for bidding, approval, and installation of the Entry Systems ES4100 door closer.
