Hager 5100 Series Surface Mount Door Closer – Heavy-Duty Grade 1, Adjustable 1–6, ADA Barrier Free, UL Fire Rated, Gold, 5123 Pull Side Stop Arm (Regular Mount Only)
The Hager 5100 Series Heavy-Duty Surface Door Closer with the 5123 Pull Side Stop Arm is built for high-traffic commercial openings that demand durability, code compliance, and clean pull-side installation. Rated to Grade 1 (ANSI A156.4) with adjustable power sizes 1–6, it delivers smooth, controlled closing on doors up to 330 lbs. This configuration is Regular (pull-side) mount only, does not include a hold-open function, and is therefore suitable for fire-rated doors when installed per code.
Key Features
- Grade 1 Heavy Duty surface closer – adjustable sizes 1–6
- 5123 Pull Side Stop Arm – non hold-open arm with integrated stop for over-travel control
- Regular (Pull-Side) Mount Only – not supplied or approved for top jamb or parallel arm mounting
- ADA Barrier Free compliant opening forces (ANSI A117.1)
- UL/cUL Listed for up to 3 hours; UL10C Positive & UL10B Neutral Pressure rated
- Adjustable sweep, latch, and backcheck valves; delayed action valve optional (all valves staked)
- Durable build: forged steel arm, one-piece seamless steel spring tube, precision-machined, heat-treated steel piston
- Standard gold finish; additional finishes available (ALM, BLK, BRZ, DBZ, GOL)
- Operating temperature range: -40°F to 150°F
Specifications
- Applications: Schools, healthcare, offices, retail, and public buildings
- Power: Adjustable sizes 1–6
- Maximum Door Weight: 330 lbs
- Door Thickness: 1-3/4" standard; optional 1-3/8"–2-1/4"
- Handing: Non-handed closer body
- Covers: Full plastic cover (standard); plated metal cover (optional)
- Fasteners: Self-reaming, self-tapping wood & machine screws; sex nuts & bolts
- Springs: One-piece seamless steel spring tube; double heat-treated, steel-tempered springs
Certifications & Compliance
- BHMA Certified to ANSI A156.4 (adjustable 1–6)
- ADA compliant (ANSI A117.1 Accessibility Code)
- UL/cUL Listed for up to 3 hours (no hold-open; fire-door suitable when installed per code)
- UL10C Positive Pressure & UL10B Neutral Pressure rated
- 5100 Door Closer EPD
What’s Included
- Hager 5100 Series Surface Door Closer body
- 5123 Pull Side Stop Arm – hardware for regular (pull-side) mount only
- Standard fastener pack and cover (gold finish)
Mounting & Application Notes
- This variant is Regular (pull-side) mount only; it is not supplied for top jamb or parallel arm mounting.
- No hold-open function is provided or permitted on fire-rated openings.
- Non-handed design allows installation on left- or right-hand doors.
Recommended Pairings
To maximize hinge life and assist in achieving ADA compliance, use anti-friction or ball bearing hinges with this closer.
Important Notes
- ADA/Barrier Free Adjustment: Any BHMA/ANSI A156.4 certified closer, including the 5100, when adjusted to ADA or
