Application Fit

• Opening Size: Designed to retrofit an existing 38" wide x 85" tall drywall opening.
• Wall Build: Fits 2x4 wood stud walls with 5/8" drywall on both sides (≈ 4-7/8" overall thickness).
• Handing: Right Hand Reverse (RHR) swing.
• Use Case: Perfect for interior renovations, tenant improvements, and facility upgrades.

Door Construction

• Skins: 18-gauge galvannealed steel with prime gray, paint-ready finish.
• Core: Polystyrene insulated (non-rated) for rigidity and thermal efficiency.
• Edges & Reinforcements: Interlocked seams with heavy backing plates at hinge and lock locations.
• Prep: Factory prepped for standard commercial hinges and lockset.

KD Drywall Slip-On Frame (4-7/8" Wall)

• Frame Type: Knock-down slip-on frame designed to sleeve over drywall walls.
• Wall Fit: Sized specifically for 4-7/8" finished thickness (2x4 stud + 5/8" drywall each side).
• Anchorage: Compression anchors and base attachments secure frame into existing stud wall construction.
• Installation: Ships in sections for easy handling and quick assembly on site.

Advantages

• Retrofit-first design — install without tearing out existing drywall or studs.
• Sized around finished opening and wall thickness for accurate fit.
• Prime coat finish ready for field topcoat to match existing interiors.
• USA made with short 3–4 week production lead times.

Key Specifications
