Application Fit

• Opening Size: Sized for existing 38" wide x 85" tall drywall openings.
• Wall Build: For 2x6 wood stud walls with 5/8" drywall each side (≈ 6-3/4" overall thickness).
• Handing: Right Hand Reverse (RHR) swing.
• Use Case: Ideal for heavy-duty interior partitions in schools, healthcare, offices, and government buildings.

Door Construction

• Skins: 18-gauge galvannealed steel with prime gray, paint-ready finish.
• Core: Polystyrene insulated (non-rated) for added rigidity and efficiency.
• Edges & Reinforcements: Interlocked seams with heavy-duty backing plates at hinge and lock locations.
• Prep: Factory prepped for standard commercial hinges and lockset hardware.

KD Slip-On Frame for 6-3/4" Walls

• Type: Knock-down slip-on frame designed for retrofit drywall openings.
• Fit: Engineered to sleeve 6-3/4" finished wall thickness (2x6 studs + 5/8" drywall each side).
• Anchorage: Secures to wall with compression anchors and base attachments.
• Installation: Ships in sections for efficient transport and quick jobsite assembly.

Advantages

• Retrofit-first design installs without demolition of existing drywall.
• Exact sizing ensures a precise, professional fit for 2x6 walls.
• Prime-coated finish ready for your field-applied topcoat.
• Proudly USA made with consistent 3–4 week production times.

Key Specifications
