Phoenix Titan 44 Series Rim Exit Device with Keyed Lever - Model 44E0-3 - Fits 28" to 36" Medium Stile Hollow Metal or Wood Doors - Aluminum Finish - Schlage C Keyway, Dogging, 2-3/4" Backset, 5/8" Stainless Steel Latch - Grade 1, UL Listed

Phoenix Architectural Hardware Titan 44 Series – Model 44E0-3 with Keyed Lever is a Grade 1 rim exit device designed for medium stile commercial doors between 28" and 36" wide. This version includes an outside keyed entrance function lever with a Schlage C keyway, allowing secure key-controlled entry while maintaining free egress from the inside.

The device features a stainless steel 5/8" throw latch with deadlatch, a 2-3/4" backset, and a minimum 4-1/2" stile. The rail is cuttable to size. Since this is a non-fire-rated model, Allen key dogging is included for hold-open convenience.

• Model: 44E0-3 (Rim Exit Device with Keyed Lever)
• Door Width: 28"–36"
• Keyway: Schlage C keyway
• Dogging: Yes (Allen key)
• Latch: 5/8" stainless steel throw latch with deadlatch
• Backset: 2-3/4"
• Design: Non-handed, field reversible
• Finish: Aluminum (AL)
• Compliance: ANSI/BHMA A156.3 Grade 1
• Listings: UL Listed for panic hardware
