Phoenix Titan 44 Series Fire Rated Rim Exit Device W/ Outside Pull Handle and Cylinder - Model 44E0-FR-3 - Fits 28" to 36" Medium Stile Hollow Metal or Wood Fire Doors - Aluminum Finish - Schlage C Keyway - Grade 1 - UL Listed

The Phoenix Architectural Hardware Titan 44 Series – Model 44E0-FR-3 with Outside Pull Handle and Cylinder is a fire-rated, ANSI Grade 1 rim exit device engineered for 28" to 36" medium stile hollow metal or wood fire-rated doors. This model features a durable outside pull handle paired with a Schlage C keyway lock cylinder for secure, code-compliant exterior access while ensuring free and unobstructed egress from the interior.

As a fire-rated device, the 44E0-FR-3 includes no dogging function in order to maintain mandatory latch engagement at all times. The unit incorporates a 5/8" stainless steel throw latch with deadlatch, a standard 2-3/4" backset, and requires a 4-1/2" minimum stile for proper mounting. Its non-handed, field-reversible design allows universal installation on both right and left hand doors.

Key Specifications

• Model: 44E0-FR-3 (Fire Rated Rim Exit Device with Pull Handle and Cylinder)
• Door Width: 28"–36"
• Door Type: Hollow metal or wood fire-rated doors
• Trim: Outside pull handle with cylinder
• Cylinder: Schlage C keyway (keys included)
• Dogging: None – required for fire-rated hardware
• Latch: 5/8" stainless steel throw latch with deadlatch
• Backset: 2-3/4"
• Minimum Stile: 4-1/2"
• Design: Non-handed, field reversible
• Finish: Aluminum (AL)
• Compliance: ANSI/BHMA A156.3 Grade 1
• Listings: UL Listed for fire-rated openings

Built for reliability and long-term performance, the Phoenix Titan 44 Series 44E0-FR-3 delivers fully compliant fire-rated panic hardware with secure exterior access control—ideal for schools, offices, retail stores, and other commercial facilities requiring top-tier life-safety protection.
