Your Source for R27942 Door Closers - Authorized, Trusted, and Backed by Expertise.
R27942 5 in. x 2-1/4 in. Surface Mount Door Closer - Heavy-Duty Grade 1, Adjustable Size 16, Spring Cushion Hold-Open Arm, Parallel Mount Only, Aluminum Finish
$
Item Return Policy: Assembled Per Order, Non-Returnable
Product Code: R27942-5214-SCUSHHO-ALUM
Usually Ships in 24 Hours
Orders Over $200 Qualify for FREE SHIPPING!
R27942 5 in. x 2-1/4 in. Surface Mount Door Closer - Heavy-Duty Grade 1, Adjustable Size 1–6, Spring Cushion Hold-Open Arm, Parallel Mount Only, Aluminum Finish
The Phoenix Door Controls 416 is a heavy-duty, ANSI/BHMA Grade 1 surface mount door closer configured with a spring cushion hold-open arm for controlled opening and convenient, manual hold-open. This model is designed for parallel arm (push-side) mount only, delivering a low-profile installation that stands up to high-traffic commercial use. The aluminum finish complements storefront and interior applications.
How the Spring Cushion Hold-Open Works
Spring cushion reduces shock as the door approaches full open, helping protect hinges, frames, and walls.
Manual hold-open lets you set the door to stay open at an adjustable angle (project dependent) during busy periods.
Disengage by gently pulling the door past the set point and allowing it to close under controlled speed.
Core Closer Performance
Adjustable spring power Size 1–6 to match door size, weight, and onsite conditions.
Independent closing speed and latch speed valves for smooth, reliable closing and positive latch.
Opening check (backcheck) adjustment to cushion against abrupt stops and wind gusts.
Parallel arm (push-side) mount only for a clean, vandal-resistant profile.
Fire-Door Note: Mechanical hold-open arms are generally not permitted on labeled fire-rated doors unless released by an approved life-safety system. Confirm local code and AHJ requirements before specifying.
Key Features
Grade 1 performance for demanding commercial openings
Spring cushion hold-open arm — adjustable hold-open angle with cushioned opening
Adjustable Size 1–6 spring power
Adjustable closing speed, latch speed, and backcheck
Parallel arm mount only (push-side)
Aluminum finish for a clean architectural look
Specifications
Brand / Model
Phoenix Door Controls 416
Type
Surface Mount Door Closer
Grade
ANSI/BHMA Grade 1
Spring Power
Adjustable Size 1–6
Arm
Spring Cushion Hold-Open (manual, angle adjustable)
