R7483 11-3/32 in. x 3/4 in. Door Closer - Adjustable Spring Size 2-6, Grade 1 UL10C Certified, Aluminum Alloy Body, Full Cover, Tri-Pack Regular/Top Jamb/Parallel Arm Mount, Aluminum Finish (AL)

The R7483 11-3/32 in. x 3/4 in. Door Closer in Aluminum (AL) finish is a high-strength, full-cover commercial closer engineered for demanding applications where increased closing force is required. As part of the R7483 Series, this closer is designed for heavy-duty architectural and institutional doors, making it ideal for exterior entrances, schools, and high-traffic commercial facilities.

The R7483 features an adjustable spring power range of sizes 2–6, providing strong, customizable door control for larger or exterior openings. This model is Grade 1 certified under ANSI/BHMA A156.4 and UL Listed for UL10C positive pressure fire-rated applications. While not ADA barrier-free due to its higher spring tension, the R7483 ensures consistent, controlled door closing and long-term reliability under heavy use.

Built with a rugged aluminum alloy body and a full-size architectural cover, the R7483 combines performance with aesthetics. The tri-pack mounting system allows for regular, top jamb, or parallel arm installation. Three independent regulating valves control sweep speed, latch speed, and backcheck cushioning for precise field adjustment.

Features

• Series: R7483 11-3/32 in. x 3/4 in.
• Model: Adjustable spring power sizes 2–6
• Grade 1 certified – ANSI/BHMA A156.4 compliant
• UL Listed – complies with UL10C positive pressure fire door standards
• Aluminum alloy body with full-size architectural cover
• Three independent valves for sweep, latch, and backcheck adjustment
• Tri-packed – includes hardware for regular, top jamb, or parallel arm mounting
• Non-handed – suitable for left- or right-hand doors
• Architectural finishes available: AL (Aluminum), DU (Duronotic), US3 (Polished Brass), CH (Polished Chrome)
• Supplied with wood and machine screws

The R7483 11-3/32 in. x 3/4 in. Door Closer provides powerful, adjustable door control for commercial and institutional openings. With a full cover design and Grade 1 construction, it’s built for durability, safety, and high-performance operation in heavy-use environments.

Recommended Applications: Exterior aluminum storefronts, heavy commercial doors, hollow metal and wood doors, warehouses, offices, and institutional buildings requiring adjustable high spring force.

Finish: AL – Aluminum

Order from Door Closers USA or call 866-232-5673 / text 210-275-8966 for technical support and volume pricing.
