Key Features

• Purpose-built for steel stud wall with veneer applications
• Fits 39-1/2" x 86" opening (verify rough opening and substrate)
• Pre-glazed 1/4" tempered safety glass for commercial use
• ADA & IBC compliant entrance assembly
• Grade 1 UL Listed, ANSI/BHMA certified hardware throughout
• Architectural clear anodized finish on rails and stiles

What’s Included (Pre-Installed / Packaged)

• Alumitrex™ storefront door leaf, sized for 39-1/2" x 86" opening
• 1/4" tempered safety glass, factory pre-glazed with glazing vinyl
• Heavy-wall aluminum rails/stiles (clear anodized)
• Heavy-duty deadbolt (Grade 1, UL Listed, ANSI/BHMA certified)
• ADA hydraulic door closer (Grade 1, UL Listed, ANSI/BHMA A156.4 compliant)
• Heavy-duty pivot hinges (top and bottom; ANSI/BHMA certified)
• Solid aluminum pull (interior) and push bar (exterior) set (ANSI/BHMA A156.6 compliant)
• Fastener kit and mounting hardware for door/closer/locks (storefront components)

All primary hardware components are Grade 1, UL Listed, and ANSI/BHMA certified.

Compliance & Certifications

• ADA compliant approach, clearances, and operability
• IBC compliant storefront entrance assembly
• UL Listed and ANSI/BHMA Grade 1 hardware
• Commercial tempered safety glass

Wall Type & Mounting (Steel Stud Wall with Veneer)

Designed for exterior steel stud framing with a veneer façade (brick, stone, stucco, or panel). Provide continuous structural backing at jambs and head. Typical attachment uses self-drilling structural screws or engineered anchors into steel studs/headers (by installer to suit site conditions).

• Shim and anchor at manufacturer-recommended points
• Coordinate weather-resistive barrier, flashings, and sealant with façade
• Seal perimeter with commercial-grade backer rod and sealant
• Verify smooth swing, clear threshold, and ADA approach clearances

so installers can select the correct type, length, and thread for the project’s stud gauge and header design.

Specifications

• Opening Fit: 39-1/2" wide x 86" tall
• Glazing: 1/4" tempered safety glass, pre-glazed
• Rails/Stiles: Heavy-wall aluminum, clear anodized
• Hardware: Grade 1 UL Listed, ANSI/BHMA certified (closer, deadbolt, pivots, pull/push hardware)
• Use: Exterior storefront entries on steel stud wall with veneer
• Origin: Made in USA
• Lead Time: 3–4 week production

Quality & Packaging

• Factory pre-glazing and hardware preparation to reduce install time
• Protective wrapping and crating for freight transit
• Installation instructions included

Notes

• Verify rough opening, stud layout, and veneer details prior to ordering
• Coordinate threshold/transition with exterior grade and waterproofing
• Site conditions may require alternate anchors or sealants (by installer)
