Trulite 200 Series Narrow Stile Commercial Glass Entry Door 36" x 96" Right Hand - Clear Anodized Aluminum - 1/4" Tempered Glass (Ships Separately - Field Glazed) - ADA Entrance Door with Frame & Grade 1 Hardware (3-4 Week Production Time)
If you need a complete commercial aluminum glass entrance door that installs smoothly and performs reliably, the Trulite 200 Series Narrow Stile Entrance provides a professional storefront solution designed for light commercial traffic environments. This entrance package includes the door, frame, ADA compliant threshold, and Grade 1 hardware to simplify ordering and ensure compatibility between components.
Manufactured by Trulite Glass & Aluminum Solutions and supplied through Door Closers USA, this entrance system features durable tie rod construction, dry glazed glass retention, and commercial grade hardware engineered for long term performance in retail storefronts, offices, medical buildings, and commercial tenant spaces.
Glass ships separately and must be glazed in the field.
Why Contractors Choose This Entrance
- Complete entrance package reduces coordination between suppliers
- Compatible frame, hardware, and threshold included
- Grade 1 commercial hardware for dependable operation
- ADA compliant threshold helps meet accessibility requirements
- Narrow stile design provides modern architectural appearance
- Dry glazed construction simplifies glass installation
- Tie rod assembly improves structural strength
- Supplied through Door Closers USA for complete entrance system support
Estimated Production Time
3-4 Week Production Time
Complete Entrance Package Includes
- Trulite 200 Series narrow stile aluminum glass door
- Commercial aluminum entrance frame
- ADA compliant threshold
- Grade 1 door closer
- Commercial mortise lock
- Lock indicator
- Cylinder
- Cylinder guard
- Push pull handle set
- Thumb turn
- Top and bottom pivots
- Glass stops
- Bottom brush door sweep
- Tempered safety glass (ships separately)
Common Applications
- Retail storefront entrances
- Office building entry doors
- Medical office entrances
- Restaurant entrance doors
- Shopping center tenant spaces
- Commercial aluminum glass door replacements
- Light commercial traffic buildings
Door Dimensions
- Door Size: 36" x 96"
- Handing: Right Hand
- Door Thickness: 1-3/4"
- Stile Type: Narrow stile
Frame Dimensions
- Exact Frame Size: 39.5" width x 97.75" height
Recommended Rough Opening
- Rough Opening Width: 40"
- Rough Opening Height: 98"
Construction Details
- Tie rod corner construction for structural durability
- Dry glazed system for secure glass retention
- 6063 aluminum construction
- EPDM glazing gaskets
- Adjustable glass jack to help center glazing
- Commercial grade hardware reinforcement
Glass Specifications
- Glass Type: Tempered safety glass
- Glass Thickness: 1/4"
- Glazing Method: Dry glazed
- Glass is shipped separately to prevent damage during transportation
- Glass must be installed and glazed in the field
- Compatible with 1/4", 5/8", or 1" glazing infill options depending on configuration
Finish
- Finish: Clear Anodized Aluminum
- Conforms to AAMA anodized finish standards
Hardware Specifications
- Grade 1 commercial door closer
- Commercial mortise lock
- Cylinder with thumb turn
- Push pull hardware set
- Top and bottom pivots
- Bottom brush door sweep
- Extruded aluminum ADA compliant threshold
- Weatherstripping utilizing wool pile or EPDM gasket
Field Glazing Requirement
Glass is shipped separately from the door and frame to reduce risk of freight damage. The installer is responsible for glazing the glass into the door using the supplied glass stops and glazing components during installation.
Trulite Entrance System Overview
Trulite 200, 300, and 500 Series entrance doors are engineered for reliable performance across varying traffic levels. The 200 Series narrow stile configuration is designed for normal duty commercial openings, while maintaining a clean, modern storefront appearance.
Compatible with Trulite storefront framing systems including CG400, CG450, CG451, CT451, and WW450 systems, allowing integration into a complete storefront entrance system.
ADA Accessibility
This entrance system includes an ADA compliant threshold and can be configured to meet accessibility requirements when installed properly. Final compliance depends on hardware configuration, clearances, and installation conditions.
Source of Supply
This Trulite entrance system is supplied through Door Closers USA to ensure compatibility between hardware, threshold, and entrance components. Purchasing the complete entrance package from Door Closers USA helps reduce installation issues and simplifies coordination between trades.
