Water Leaking Under Commercial Door? Fix the Threshold Problem


Water Leaking Under Commercial Door? Fix the Threshold Problem

If you have water leaking under a commercial door, the issue is usually not the door itself - it’s thethreshold profile (too low, too flat, worn out) and/or missing bottom sealing components.When the threshold is wrong, rainwater and wind-driven water will push right through the opening.

This problem solver shows you how to identify the cause, what to measure, and whichcommercial door threshold solutions stop water intrusion the fastest.


Why Water Comes Under Commercial Doors

  • Threshold profile is too low or flat for an exterior opening
  • Exterior slab slopes toward the building and funnels water to the door
  • Worn or damaged threshold (dents, gaps, missing inserts)
  • Door bottom clearance is too large for the existing threshold
  • No door sweep (or an ineffective sweep) allowing wind-driven water
  • Storefront doors using the wrong threshold type (common leak cause)

Step 1 - Identify the Leak Pattern (This Tells You the Fix)

  • Leak across the full width: threshold is too low/flat or worn
  • Leak mostly at latch side: door is out of alignment or sweep isn’t sealing there
  • Leak only during storms/wind: needs better sealing + sweep combo
  • Leak at storefront entrance: often needs storefront-specific threshold profiles
Important: Caulk alone is rarely a permanent fix. The correct solution is aweatherproof threshold profile that creates a physical water barrier, often paired with acommercial door sweep.

Step 2 - Quick Measurements That Matter

To choose the correct threshold solution, measure:

  • Door bottom gap (largest measurement across the opening)
  • Threshold width needed to cover the sill (common widths: 3", 4", 5", 6")
  • Door type (hollow metal, storefront aluminum, wood)
  • Exposure (protected overhang vs. fully exposed rain/wind)

Best Threshold Solutions to Stop Water Intrusion

Fix A - Exterior Weatherproof Thresholds (Best Starting Point)

Designed specifically for exterior commercial openings exposed to rain, snow, and standing water. These profiles improve sealing while maintaining a safe transition at the doorway.

Shop Exterior / Weatherproof Thresholds

Fix B - Tall / High Profile Thresholds (Severe Leaks or Large Gaps)

Best when water intrusion is heavy or when the door bottom gap is too large for a standard saddle threshold. Taller profiles create a stronger barrier and better coverage.

Shop Tall / High Profile Thresholds

Fix C - Threshold + Door Sweep Combo (Stops Wind-Driven Rain)

For the best performance, pair the correct threshold with a commercial sweep. The threshold blocks water at the floor line; the sweep seals the moving door edge.

Shop Commercial Door Sweeps


Storefront Doors: A Common Leak Scenario

If water is coming under a storefront aluminum / narrow stile door, it’s often because a generic flat thresholdwas installed instead of a storefront-specific profile. Storefront systems typically seal best withthresholds designed for glass entry applications.

Shop Storefront Door Thresholds


ADA Note (Don’t “Fix” Water and Create an ADA Violation)

If this door is part of an accessible route, you may need a solution that stops water while maintaining ADA-friendly height and transitions.If an inspector is involved, start with ADA compliant options and build weather sealing around that requirement.

Shop ADA Compliant Commercial Door Thresholds


Common “Quick Fix” Mistakes That Keep the Door Leaking

  • Installing another flat, low profile threshold
  • Over-caulking without changing the threshold profile
  • Using an interior-only threshold outdoors
  • Ignoring a large door bottom gap (needs taller profile or sweep combo)
  • Using the wrong threshold style on storefront doors

Shop Commercial Door Threshold Solutions

Need to Stop Water Fast?

Start with Exterior / Weatherproof Thresholds. If the leak is severe or the gap is large, move up to aTall / High Profile threshold and pair it with a commercial door sweep.

Browse Weatherproof Threshold Solutions
